Efficiency 20kva-180kva Rack Mounted Modular Ups 50/60hz

Name: Efficiency 20kva180kva Rack Mounted Modular Ups 5060hz
Brand: Coolnet
Price: 1100 USD

Wholesale Efficiency 20kva-180kva Rack Mounted Modular Ups 50/60hz from china suppliers

Brand Name : Coolnet

Model Number : AC020-AC180

Place of Origin : China,Anhui

MOQ : 1set

Price : 1100-11500USD/set

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 1000set/month

Delivery Time : 15days

Packaging Details : Export packaging that meets overseas transportation requirements

System Display : LED + 7 Inch Touch LCD

Input Frequency : 50/60Hz

Rate Voltage : 380/ 400/ 415VAC(L-L), 220/ 230/ 240VAC(L-N)

Rate Freq : 50/60Hz

Dimensions : 440*555*85(2U)

Ups Capacity : 20kva -180kva

System Efficiency : Normal Mode≥96%;BaƩ Ery Mode≥96%

Rated Output Voltage : 380/400/415VAC Or 220/230/240VAC

Contact Now

Product Description

The Online Uninterruptible Power Supply (UPS) is an innovative and reliable solution designed to cater to the critical power needs of server rooms, telecommunication systems, and other essential equipment that requires a consistent power supply. This state-of-the-art UPS is not only a testament to technological advancement in power backup solutions but also a testament to the meticulous engineering aimed at ensuring seamless operations in various professional settings.

Our Online Uninterruptible Power Supply is a premium solution for anyone looking for a reliable, scalable, and user-friendly power protection system. It is especially suitable for server room-up requirements, where uptime is non-negotiable, and telecommunication modular UPS setups demand high-performance and adaptable power protection solutions. With its advanced features, flexible voltage options, and extensive capacity range, this UPS stands as a paragon of power backup excellence.

Efficiency 20kva-180kva Rack Mounted Modular Ups 50/60hz

Technical Parameters

Model CNM	020/10	030/15	040/20	040/10	045/15	060/15	080/20	090/15	120/20
Rate Power	20KVA/20KW	30KVA/30KW	40KVA/40KW	40KVA/40KW	45KVA/45KW	60KVA/60KW	80KVA/80KW	90KVA/90KW	120KVA/120KW
Main input
Input	3P5W(3P+N+PE)
Rate Voltage	380/400/415VAC(L-L);220/230/240VAC(L-N)
Rate Freq	50/60Hz
Input PF	>0.99
Current Distortion	THDi<3%(100%Linear load)
Voltage Range	304-478VAC(L-L)full load;304-228VAC(L-L)power derate from 100%to 75%
Freg.Range	40-70Hz
Battery
Rate voltage	±240VDC(adjustable for 32-44 sections)
Charging Capacity	20%*Pout
Charging Accuracy	±1%
Bypass
Rate Voltage	380/400/415VAC(L-L);220/230/240VAC(L-N)
Voltage Range	Range:-40%-+25%,Settable,default-20%~+15%
Overload	110%,long time operation;110%<load<125%,5 mins 125%<load<150%,1min;>150%,1second
Inverter
Rate Voltage	380/400/415VAC(L-L);220/230/240VAC(L-N)
Rate Freq	50/60Hz
Output PF	1
Voltage Accuracy	±1.0%
load Response	<5%(20%-80%-20%step load)
Recovery Time	<20ms(0%-100%-0%step load)
Output THDu	<1%(linear load),<5%(non-linear load according to IEC 62040-3)
Overload	110%,1 hour;125%,10 mins;150%,1min;>150%,200ms
Frequency Accuracy	0.1%
Synchronize Window	Settable,±0.5Hz-±5Hz,default±3Hz
Slew Rate	Settable,0.5Hz/S-3Hz/S,default 0.5Hz/S
Phase Accuracy	120°±0.5°
System
Efficiency	Normal Mode≥96%;Battery Mode≥96%
Display	LED+7inch touch LCD
Certification-Safety	IEC62040-1,IEC60950-1
Certification-EMS	IEC62040-2;IEC61000-4-2(ESD);IEC61000-4-3(RS);IEC61000-4-4(EFT);IEC61000-4-5(Surge)
IP Degree	IP20
Configuration	USB,RS232,RS485,Dry contact,Cold start
Option	SNMP card,AS400 card,Parallel kit,LBS,Air filter,Bottom entry kit,Wheels kit
Environment	0-40℃(operation);-25~70(storage);0-95%(Humidity,non-condensing)
Noise(dB)(1meter)	65dB @100%load,62dB @45%load
Dimension
Cabinet(WDH)mm	482700396(9U, wheels not included)			482700662(15U, wheels not included)				482700840(19U, wheels not included)
Module(WDH)mm	44055585(2U)

Applications

The Rack Mounted Modular design of the Coolnet UPS is perfect for data centers and server rooms where space is at a premium. The compact form factor allows for efficient use of valuable floor space while providing top-tier power protection. The double conversion power supply architecture guarantees that the load is continuously supplied with clean power, free from all main power anomalies.
One of the key applications of the Coolnet UPS is within the uninterruptible power supply data center environment. Data centers are the backbone of the modern digital economy, housing servers, and networking equipment that must operate around the clock without interruption. The Coolnet UPS ensures that these critical components are shielded from power interruptions, which can lead to data loss, downtime, and significant financial repercussions.
Additionally, the Coolnet AC020-AC180 is suitable for medical facilities that require an uninterrupted power supply for life-saving equipment, industrial settings with machinery that could be damaged by sudden power losses, and any other scenario where power reliability is non-negotiable. With its 50Hz/60Hz frequency voltage regulator, the UPS can cater to a variety of equipment and regional power grid standards, further solidifying its position as a versatile power protection solution.
In summary, the Coolnet AC020-AC180 offers a comprehensive solution to a range of power supply challenges. Whether it's for a data center, a medical facility, or an industrial plant, this UPS provides the reliability and adaptability necessary to maintain continuous operations and protect against potential power-related damages.

Support and Services

Our Online Uninterruptible Power Supply (UPS) products come with comprehensive technical support and services designed to provide you with a seamless experience. Our support includes:

Remote Troubleshooting: Our technical team is available to diagnose and solve issues remotely, reducing the need for on-site visits.

Self-Help Resources: A suite of online resources including FAQs, user manuals, and how-to guides to help you resolve common issues on your own.

Training: Comprehensive training sessions for your team on how to operate and maintain the UPS, ensuring your staff is well-equipped to handle the system.

We are committed to providing you with reliable and efficient support to ensure your critical power systems are always operational. Our technical support team is dedicated to delivering the highest level of service to meet your unique needs.
